Brother LX-3125 User Manual. Size: 1.28 Mb. IMPORTANT MESSAGE!! Brother International Corporation is committed to providing the assistance necessary to ensure the Brother product you purchased meets your expectations. Knowing Your Sewing Machine. Please refer to your instruction manual for further instructions. Operation manual, Basic sewing and mending machine. Read online or download PDF. Brother LX-3125 User Manual Manuals Directory ManualsDir.com - online owner manuals library Search. Brother VX-1435, LX-3125 User Manual. Size: 5.02 Mb. KNOWING YOUR. SEWING MACHINE. SEWING BASICS. Use only accessories recommended by the manufacturer as contained in this manual. Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into.
Should you experience problems with your product, please read the Operation Manual or the Quick Reference Guide first, before returning your product to the place of purchase. Brother International Corporation is committed to providing the assistance necessary to ensure the Brother product you purchased meets your expectations.
For assistance or to find the address of your nearest Service Center, please call: 877-Brother (276-8437).
Further information is also available at our Brother Solutions Center site at http://solutions.brother.com
To register your product online and enter for your chance to win $1,000, please visit www.brother-usa.com/Registermybrother
Please retain this sheet for future use. We are here to help you.
Si experimenta problemas con su producto, lea el Manual de operación o la Referencia rápida antes de devolver su producto al lugar de adquisición. Brother International Corporation se compromete a ofrecer la asistencia necesaria para asegurar que el producto Brother adquirido satisfaga sus expectativas.
Para ayuda, o para encontrar la dirección del Centro de servicio más cercano, llame a: 877-Brother (276-8437).
También podrá encontrar más información en nuestro Centro de soluciones Brother, cuyo sitio es: http://solutions.brother.com
Para registrar en línea su producto y tener la posibilidad de ganar 1.000 dólares, visite www.brother-usa.com/Registermybrother
Conserve esta hoja para uso futuro. Estamos aquí para ayudarle.
XE5240-001
Solution Center | Quick Reference Guide | |||||
To eliminate unnecessary repairs, listed below are common problems and possible | Knowing Your Sewing Machine | |||||
solutions. Please refer to your instruction manual for further instructions. | Name of Machine Parts and Their Functions | |||||
Needle Breaks | 1 | 2 | ||||
Needle is inserted incorrectly | 3 | 7 | E | |||
Needle clamp screw is loose | 8 | |||||
Bent needle is being used | ||||||
9 | D | |||||
Upper threading is not correct | ||||||
Upper thread tension is set too tight/high | C | |||||
Needle and/or thread for fabric being sewn is not correct | 5 | B | ||||
Material pulled and/or moved excessively during sewing | ||||||
6 | ||||||
Upper Thread Breaks | ||||||
Upper thread is not correct | 0 | |||||
Upper thread tension is set too high/tight | A | F | ||||
Upper thread is too large for the needle eye | ||||||
Lower Thread Breaks | 4 | |||||
Lower thread may be entangled in shuttle | 1 Pattern Selection Dial | 7 Presser Foot Holder Assembly | ||||
Lower thread tension is set too tight/high | ||||||
Choose from 10 different stitches | 8 Presser Foot Screw | |||||
Lower threading is not correct | ||||||
2 Buttonhole Fine-Adjusting Screw | 9 Presser Foot (Zigzag) | |||||
Loops on Top or Bottom of Fabric Form During Sewing | For use if the stitching on the two sides of the | 0 Needle Plate | ||||
buttonhole do not appear uniform | A Shuttle Hook | |||||
Upper or lower thread tension not set correctly | ||||||
3 Thread Take-up Lever | B Bobbin Case | |||||
Upper threading is not correct | ||||||
Guide thread through the lever from right to left | C Feed Dogs | |||||
Incorrect bobbin being used | ||||||
4 Flat Bed Attachment with Accessory | D Needle | |||||
Material Tends to Pucker During Sewing | Storage | E Needle Clamp Screw | ||||
For easy storage of included accessories | F Shuttle Cover | |||||
Upper or lower thread tension is set too high/tight | ||||||
5 Upper Tension Control Dial | ||||||
Upper threading is not correct | ||||||
This controls the tension of the upper thread | ||||||
Thread may be caught or is catching on something | ||||||
6 Reverse Sewing Lever | ||||||
Lower thread is unevenly wound on bobbin | ||||||
To sew in reverse | ||||||
Incorrect bobbin being used | ||||||
Skips Stitches | N | G Thread Cutter | ||||
Needle is not sharp and/or straight | I H | H Spool Pin | ||||
Needle is inserted incorrectly | Pull up on spool pin to level thread | |||||
Needle and/or thread for fabric being sewn is not correct | O | I Bobbin Winder | ||||
Upper threading is not correct | Place unfilled bobbin on winder | |||||
Lint and/or debris caught on underside of needle plate | J Handwheel | |||||
Machine Runs Slow and/or Noisy | J | Use for lower threading | ||||
K Foot Controller Jack | ||||||
Machine may require cleaning or lubrication | L | G | Insert plug in jack to operate foot controller | |||
Lint and/or debris may be caught in the shuttle and/or feed dog assemblies | L Presser Foot Lever | |||||
M | ||||||
Used to raise and lower the presser foot | ||||||
Bobbin is Wound Incorrectly | K | |||||
M Main Power/Sewing Light Switch | ||||||
Use a small pair of scissors to remove thread | Turns your machine/sewing light on | |||||
N Built-in Handle | ||||||
Ideal for easy and efficient transporting | ||||||
Brother International Corporation recommends the use of genuine parts and supplies and proper maintenance | O Thread Guide/Bobbin Winding Pre-tension | |||||
to keep your product running smoothly. Many of our resellers carry genuine Brother parts, accessories and | Disc | |||||
supplies. If you are unable to locate these items, please visit us online at | Used when winding the bobbin and then | |||||
www.brothermall.com. | threading the machine | |||||
Toll Free Phone 877-276-8437 | ||||||
Winding the Bobbin
1 | 2 |
Pass the thread through the hole | ||
Pull up on the thread spool pin to lengthen the height. Place the thread spool on the pin | on the bobbin from inside. Use | |
upper hole, not both. Place on | ||
and pass the thread around the bobbin winder pre-tension disc. | ||
bobbin shaft and slide to the right. | ||
3 | 4 | CAUTION |
Not winding the bobbin properly may cause the thread tension to loosen, and may break the needle.
While holding the end of the thread, | When the bobbin starts to spin | 1 Wound evenly | |
press the foot controller to begin | slowly and becomes full, release | ||
winding the thread. Cut the thread | the foot controller. Cut the thread, | 1 | 2 Wound poorly |
from the top and proceed winding. | slide the bobbin winding shaft to | 2 | |
the left and remove the bobbin. | |||
Inserting the Bobbin | |||
1 | 3 | 4 | |
Raise the needle to its highest position and remove the bobbin case by pulling the latch.
2
Hold the bobbin case as shown. Insert the bobbin with the thread coming from the bottom toward the top and the thread tail hanging out of the bobbin case.
Pull the trailing thread through the slot, down and to the left, until it enters the delivery eye under the tension spring. CAUTION: Make sure you set the bobbin so the thread unrolls in the right direction. If the thread unrolls in the wrong direction, it may cause the thread tension to be incorrect or break the needle.
Holding the bobbin case by the latch, align your finger with the top opening of the shuttle race, insert the case into the shuttle race and release the latch.
Threading the Needle
1
Raise the presser foot lifter.
2 | 3 | 4 |
Raise the thread take-up lever to | Place the thread spool on the | Pass the thread through the thread guide and down the |
its highest position by turning the | spool pin. | right channel on the front of the machine. |
handwheel. | (Don’t forget to pull up the pin) | |
5 | 6 |
Pass the thread into the thread tension discs or behind the | Grasp the thread on both sides of the tension disc and pull to |
thread tension dial from the right to the left. | ensure it is in place. |
7 | 8 |
Guide the thread up the left channel, clear to the back of the opening around | Thread the needle from front to back and pull |
the take-up lever and back down the left side of the channel to thread the | out about 2” of thread. |
take-up lever. |
2 | 3 |
Brother Lx 3125 Instruction Manual
Raise the needle to its highest position, | Slide the latch levers out from the |
pull the latch and remove the bobbin | retaining ring. |
case. |
Remove the power plug from the outlet.
4
Brother Sewing Machines Manuals Free
Remove the retaining ring.
5 | 6 | 7 |
Remove the hook by grasping the center | Remove any accumulated lint and | Grasp the center post of the hook, match | ||||||||||||
post and pulling out. Note its position | thread with a brush. | the hook position opposite the driver and | ||||||||||||
related to the driver. | insert. | |||||||||||||
8 | 9 | |||||||||||||
Insert the retaining ring with the notch | Push the latch levers into their locked |
up. | position. Replace the bobbin case. |
Relative Chart of Sewing Fabrics,
Needles and Thread Combinations
Sewing Fabrics | Needle Sizes | Thread Sizes | ||
Very Thin | Fine tricot, Fine lace, Thin linen, | #65/9 | Cotton: 80 | |
Silk, Organza, Chiffon | Synthetic/Polyester Long Fiber | |||
Fine Mercerized Cotton | ||||
Lightweight | Voile, Taffeta, Synthetics, Silk, | #75/11 | Cotton: 60-80 | |
Batiste | Silk: “A” | |||
Synthetic/Polyester Long Fiber | ||||
Mercerized 50 | ||||
Medium Weight | Cotton, Gingham, Poplin, | #90/14 | Cotton: 50-60 | |
Percale, Pique, Satin, Velvet, | (Supplied with | Silk: “A” | ||
Lightweight wool, Fine | your machine) | Synthetic/Polyester Long Fiber | ||
corduroy, Suitings, Linen, | Mercerized 50-60 | |||
Muslin | ||||
Heavyweight | Denim, Gabardine, Tweed, | #100/16 | Cotton: 40-50 | |
Corduroy, Canvas, Duck | Mercerized Heavy Duty | |||
Polyester Long Fiber | ||||
Knits | Single knit, Double knit, Jersey, | #90/14 | Cotton Wrapped Polyester | |
Tricot | (Ball point) | Polyester Long Fiber | ||
Uses common replacement accessories: | ||||
Bobbin: | Class 15 | |||
Needle: | Standard sewing machine needles | |||
Light Bulb: Small screw base sewing machine bulb | ||||
Utiliza accesorios comunes de remplazo: | ||||
Carretel: | Clase 15 | |||
Agujas: | Agujas estándares para máquina de coser. | |||
Bombilla: | Para máquina de coser con base roscada pequeña | |||
